Transition Spire Alloy Complete Bike - Sram NX

Loose Cycles

Transition Spire Alloy Complete Bike - Sram NX

€4.699,00

The Nimble Bruiser

Take on the biggest terrain without the penalty, Long travel doesn’t have to mean single purpose

The Spire blends DH bike capability with mid-travel efficiency in such a way it’s almost two bikes in one. A delicately tuned pedaling and pumping platform, super supple beginning stroke sensitivity and all the travel you could ask for makes for a mind bending ride. Happily climb up to your favorite challenging descent, then cruise on over to your local flow trail and you’ll be rewarded on both ends of the spectrum. Don’t be fooled though, while it’s no one-trick pony, the Spire lives to push your limits. Get in-Spired.

GIDDYUP SUSPENSION DESIGN

We want to make it as easy as possible to experience great rear suspension performance. The GiddyUp suspension system is designed to behave intuitively across a broad range of setup. Because, we get it, sometimes you just want to grab your bike and GiddyUp, without checking your setup. When you do, it will always feel good.

With nearly 24% progression and the most current evolution of our GiddyUp suspension kinematic, the Patrol has an excellent balance of support and small bump sensitivity. Anti-squat is tuned to enhance pedaling performance and provides a platform to push against when pumping, without sacrificing a bottomless feel when needed.

The GiddyUp suspension layout is tuned to work correctly with both air and coil rear shocks. Riders are able to add or remove volume spacers in the rear air shock to suit their individual riding style and there is plenty of bottom out control with air or coil shocks when things get rowdy. The Patrol has 160mm of rear wheel travel when used with the supplied 205mm x 60mm stroke shock. It is also possible to install a longer, 205mm x 65mm stroke shock to increase the rear wheel travel to 170mm if you are after a longer travel experience.

A suggested sag range of 27 - 33% allows the rider to tune the feel of the bike; from a firm and snappy jump and slash mode, to a more supple and active full on party mode. Wherever you end up, you can focus on the trail without remotes, levers or knobs. Just grab your bike and GiddyUp.

Specification

FRAMESpire Alloy 170mm
SHOCK: Fox Float X Performance 2 Position (205x65)
FORK: Marzocchi Bomber Z1 Air 170mm Travel/44mm Offset
HEADSET: FSA NO.55R/57
STEM: RaceFace Aeffect R (40mm)
HANDLEBAR: RaceFace Chester 35 SM (780x20) MD/LG/XL/XXL (780x35)
GRIPS: Sensus Lite
SEAT: ANVL Forge Chrome
SEATPOST: OneUp Dropper Post
BRAKES: SRAM Code R or SRAM Guide RE 4-Piston
BRAKE DISCS: SRAM Centerline (220mm/200mm)
SHIFT LEVER: SRAM NX Eagle MMX
DERAILLEUR: SRAM NX Eagle MMX
CASSETTE: SRAM PG 1230 (10-50t)
CHAIN: SRAM NX Eagle
BASH GUIDE: OneUp
CRANKSET: SRAM Descendent 6K DUB (30t/165mm)
WHEELS: Stans Flow D
FRONT TIRE: Schwalbe Magic Mary, Super Trail, Soft (29x2.4)
REAR TIRE: Schwalbe Big Betty, Super Trail, Soft (29x2.4)
INCLUDED: Tubeless Valves & Stans Sealant (6oz)


Please note: Transition reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materials.


You can find more information about the Spire HERE
